HEPA Air Filter Testing Equipment ISO 5011 SAE J726 Standard

HEPA Air Filter Testing Equipment ISO 5011 SAE J726 Standard

1. Filtering Pipe

2. Upstream Sampling

3. Upstream Pipe

4. Static Pressure Ring

5. Test Cartridge

6. Clamp Cylinder

7. Downstream Pipe.

8. Downstream Sampling

9. Tapered Pipeline

10.Current Board

11.Flow Nozzle Assembly

12.Handicraft Door

13.Deteetion Door

14.Air Inlet Joint

15.Inlet Diameter

16.Exhaust Pipe

17.Air Exhaust Dust

18.Centrifugal Blower

19.Fan Fixing Frame

20.Air Frame

21.Pipe Fixing Rack

22.Flow Nozzle Static Pressure Ring

23.Pipeline Movable Rack

24. Electric Control Box

25.Air Volume Display Meter

26. Differential Gage

27.Resistance Display Table

28.Air Flow Meter Switch

29. Resistance Meter Switch

30. Differential Pressure Switch

31.Main Motor Speed Governor

32.Governor Switch

33. Power Lamp

34.Power Switch

Executable standards

1. ISO5011

2. SAEJ726

3. JB/T9747

Characteristic

The computer automatically controls, displays, records and prints the test result. The test stand consists of air extractor, test system, flow and pressure measuring and control system, dust feeding system, electric system, computer control system and stainless steel panel.

Specifications:

Applications

 It is employed for testing the filter efficiency and blocking life of fuel filter.
