Full - auto Turntable Bottom Plate Welding Machine , 10 - 40pcs / min

Full - auto Turntable Bottom Plate Welding Machine , 10 - 40pcs / min

Specification

1. Rated Capacity:100KVA
2. Rated Primary Voltage:380V/50HZ
3. Phase Number:1
4. Adjustable Series:2
5. Rated Primary Current:263A
6. Working Air Pressure:0.4Mpa
7. M/C Weight:700kg
8. M/C Size :1070*520*1950

Feature

1. Through pneumatic motive, the electrode impacts the init to be welded, and the welding current directly heat up the machine to achieve the spot-welding action.
2. The welding time is fast and efficient, but quality is high and reliable.
3. The upper and lower working strokes of the upper motor can be regulated evenly, as well as the assistance stroke.
4. The welding machine controller has following procedures to be automatically controlled, pressurization, and power on, retaining, stop.
5. Equipped with cooling system.

.

Applications

   It is technically used to weld the screw bottom plate and fixed plate of the auto oil and fuel filters.
