High Automatic Oil Filter Making Machine / Filter Machinery 20mm - 250mm Height

Basic Information

Place of Origin:	Wenzhou, China
Brand Name:	CHANGJIANG
Certification:	CE ISO9001
Model Number:	CJJT-250B

Minimum Order Quantity:	1 SET
Price:	Negotiable
Packaging Details:	Standard export package
Delivery Time:	30 Days after deposit
Payment Terms:	30% T/T payment in advance, 70% T/T payment before shipment

Get Best Price Contact Now

Detail Information

High Light:

Filter Machinery

Product Description

High Automatic Oil Filter Making Machine / Filter Machinery 20mm - 250mm Height

Specification

Product Capacity	10pcs/min
Filter Paper Height	20-250mm
Pleating Height	10-35mm
Sizes of Steel Strips	Thickness 0.25-0.3 width 12mm Coil material: inner diameter ≥Φ150mm Outer diameter ≤Φ650mm
Motor Power	1.1KW
Power Supply	380V/50HZ
M/C Weight	400kg
M/C Size	8207501450

Features

Uses strip clamp filter pleating joint to prevent the filter element form leakage.
The machine has high automatic degree for simple operation, with unique design and long service life.
Automatically perform the complete procedure of strip molding, clamping, shutoff and resuming.
When molding, the stip bears knurling treatment, by which the paper is firmly held and hard of dropping.
The clamping height and width are easy to be adjusted and keep consistency.

Applications

The machine is professionally used for clipping the paper ends using the steel strip.
