| Place of Origin: | Wenzhou, China |
|---|---|
| Brand Name: | CHANGJIANG |
| Certification: | CE ISO9001 |
| Model Number: | CJCZ100-800 |
| Minimum Order Quantity: | 1 SET |
| Price: | Negotiable |
| Packaging Details: | Standard export package |
| Delivery Time: | 30 Days after deposit |
| Payment Terms: | 30% T/T payment in advance, 70% T/T payment before shipment |
| Supply Ability: | Engineers available to service machinery overseas |
| High Light: | filter manufacturing equipment,paper manufacturing machine |
||
|---|---|---|---|
Knife Pleating Machine Filter Manufacturing Equipment With Pre - Heating System
Quick Detail:
| Type | Knife Pleating Machine |
| Applications | Pleating for filter |
| Package | Standard Export Plywood cases |
| Certificate | CE ISO 9001 |
| After-Sales service | Engineers available to service machinery overseas |
| Delivery Time | 20 days after got Your down payment |
| Payment Term | 30% T/T payment in advance, 70% T/T payment before shipment |
Specification
Model 100-800 Pleating Machine
| Max Width | 1050mm |
| Adjustable pleating height | 10-100mm |
| Pleating speed | 0-200pleats/min (adjustable) |
| Power supply | 380V/50HZ |
| Motor Power | 0.75KW |
| Heater power | 2kw |
| Heating Temp | Normal temperature-200℃ |
| Working air pressure | 0.6Mpa |
| M/C weight | 500kg |
| M/C size | 1670×1200×1240mm |
Feature
Applications
1. The production line is applied to auto Tri-filter industry, hydraulic pressure, purification and water treatment industries etc.
2. Furthermore, we can customize the paper-pleating production line of different specifications (machine width and pleat height, this pleating machine also can pleat “M” type).
